BLIS Sample Data Files Repository
This page contains the public files currently in the BLIS Sample Files Repository.
To submit a file in this repository, please send it with the complete description and associated screenshots to your closer contact. The file will be analyzed, tested and finally put in the repository.
Please don't hesitate to send your comments to our webmaster.
| Sample Name | Author | Date | Category | Exported From | Description | Screenshots | Download |
| Sample model Office Lampo (IFC) | VTT Building and Transport | 2002/-0/6- (28: 1:8: EEST) | R2.0 Testing | ArchiCAD 7.0 | This is a test model data. File size is 1.6MByte. | 3D View |
VTT_model_new.IFC |
| AEC Systems 2002 - All Objects (IFX) | Richard See | 2002/-0/6- (13: 0:6: EEST) | R2.0 Testing | Visio Professional 2002 + IFC Model Exchange solution | This is a model file exchanged during the AEC Systems 2002 conference in Anaheim. It includes architecture + stairs + plumbing fixtures + cabinets + counters + furniture + office equipment --- in IFC-XML format. | BLIS_Bldg-4_4-Flrs_Arch_Int_HVAC.zip | |
| AEC Systems 2002 - All Objects (IFC) | Richard See | 2002/-0/6- (13: 0:6: EEST) | R2.0 Testing | Visio Professional 2002 + IFC Model Exchange solution | This one of the model files exchanged during the AEC Systems 2002 conference in Anaheim. Architecture + build-out + interiors + HVAC --- in IFC format | BLIS_Bldg-4_4-Flrs_Arch_Int_HVAC.ifc | |
| AEC Systems 2002 - Arch Shell (IFX) | Richard See | 2002/-0/6- (13: 0:6: EEST) | R2.0 Testing | Visio Professional 2002 + IFC Model Exchange solution | This is one of the model files exchanged during the BLIS demonstrations at AEC Systems 2002 in Anaheim. Architectural Shell only --- in IFC-XML format | Floor#1 Floor#2 Floor#3 Roof |
BLIS_Bldg-4_4-Flrs_ArchShell.ifx |
| AEC Systems 2002 - Arch Shell (IFC) | Richard See | 2002/-0/6- (13: 0:6: EEST) | R2.0 Testing | Visio Professional 2002 + IFC Model Exchange solution | This is the architectural shell exchanges at the AEC Systems 2002 conference demonstrations. | Floor#3 Floor#2 Floor#1 Roof |
BLIS_Bldg-4_4-Flrs_ArchShell.ifc |
| Simple 2 Building | Jiri Hietanen | 2002/-0/6- (12: 2:3: EEST) | IFC R2.0 Certification | ArchiCAD 6.5 | A 2 storey test building used in the IFC R2.0 certification process. | Floor Plan & 3D (pdf) |
IFCR2_Buildings_2.ifc |
